Bromic Affinity Smart-Heat On/Off Controllers

SKU: BH3130051

Bromic Affinity Smart-Heat On/Off Controllers

$359.00

Channel:

1 2 5

Variant

$359.00

Bromic Affinity Smart-Heat On/Off Controllers

The On/Off series allows for connected Platinum or Tungsten Collection gas or electric Bromic heaters to be turned on or off at full power capacity – providing straight forward function and usage of your outdoor heater. This series includes options for 1, 2, and 5 channel inputs. Each channel input can control up to 6000W of power or 10 gas heaters. Using the enabled Wi-Fi (compatible with 2.4GHz) or Bluetooth connectivity, control and customize your comfort via the Bromic Heating App.

3-Phase 5 Channel model is complete with an included expansion board allowing for seamless ethernet integration for a full-proof connection to your outdoor heaters or 0-10V control for Home or Business Automation integration.

Specifications

Affinity On/Off – 1 Channel

Part Number: BH3130051
Number of Channels: 1 CH
Voltage-Max Capacity Per Channel:
- 100-127V – 1kW
- 208-277V – 6kW
Operating Temperature Range: -4°F to +86°F
Non-Operating Temperature Range: -22°F to +158°F
Protection Rating: IP54
Dimensions: 11.4 x 8.0 x 4.4”
Weight: 3.1 lbs
WiFi Connectivity: 2.4GHz
Warranty: 1 Year
Approval Certification: UL 60730-1, CAN/CSA E60730-1
Heater Compatibility: Platinum Electric & Tungsten Electric

Affinity On/Off – 2 Channels

Part Number: BH3130052
Number of Channels: 2 CH
Voltage-Max Capacity Per Channel:
- 100-127V – 1kW
- 208-277V – 6kW
Operating Temperature Range: -4°F to +86°F
Non-Operating Temperature Range: -22°F to +158°F
Protection Rating: IP54
Dimensions: 11.4 x 8.0 x 4.4”
Weight: 3.6 lbs
WiFi Connectivity: 2.4GHz
Warranty: 1 Year
Approval Certification: UL 60730-1, CAN/CSA E60730-1
Heater Compatibility: Platinum Electric & Tungsten Electric

Affinity On/Off – 5 Channels

Part Number: BH3130053
Number of Channels: 5 CH
Voltage-Max Capacity Per Channel:
- 3N-220/380V – 6kW
- 3N-230/400V – 6kW
- 3N-240/415V – 6kW
- 3N-277/480V – 6kW
- 3-120/208V – 6kW
Operating Temperature Range: -4°F to +86°F
Non-Operating Temperature Range: -22°F to +158°F
Protection Rating: IP54
Dimensions: 19.7 x 13.4 x 8.0”
Weight: 24.3 lbs
WiFi Connectivity: 2.4GHz
Warranty: 1 Year
Approval Certification: UL 60730-1, CAN/CSA E60730-1
Heater Compatibility: Platinum Electric & Tungsten Electric
